PICO電源模塊

PICO電源模塊，AC-DC交直流轉換器高功率轉換器，新高電壓功率因數修正孤立交直流模塊。100-300V直流電輸出高達300瓦。UAC系列隔離輸出和5-48VDC，UL認證LPHA1和PHA1功率因數修正單元滿足低諧波失真的IEC 1000-3-2的要求。

---

Single & Dual Outputs .5" x .5" x .44" ht	1.25 Watts Up to 500 VDC Out	Series AV
Single & Dual Outputs .5" x .5" x .54" ht	1.25 Watts 600 - 1000 VDC Out	Series AV
Single Output .5" x .5" x .5"	1.25 Watts 1500 - 5000 VDC Out	Series AV
Single Output Variable Output 1.43" x 1.24" x .43" ht.	4 Watts 100-500 VDC Out	Series VV
Single Output Variable Output .500" ht.	10 Watts 1,000-5,000 VDC Out	Series VV
Single Output Variable Output .500" ht.	6 Watts 6,000-10,000 VDC Out	Series VV
High Voltage -- Programmable -- Shielded -- Short Circuit Protected	5 Watts 1-4,000 VDC Out	Series HVP
Single Output .5" ht Regulated Output	1 Watt 100 - 1,000 VDC Out	Series AVR
1/4 Brick Single Output, 4.5 - 9 VDC Input	Up to 500 VDC Out To 20 Watts	Series 6QP
1/4 Brick Single Output, 9-18 VDC Input	Up to 500 VDC Out To 40 Watts	Series 12QP
1/4 Brick Single Output, 18-36 VDC Input	Up to 500 VDC Out To 40 Watts	Series 24QP
1/2 Brick Single & Dual Outputs, 18-36 VDC Input	Up to 200 VDC Out To 75 Watts	Series LPA
1/2 Brick Single & Dual Outputs, 36-72 VDC Input	Up to 250 VDC Out To 75 Watts	Series LPB
1/2 Brick Single & Dual Outputs, 100-180 VDC Input	Up to 250 VDC Out To 75 Watts	Series LPC
1/2 Brick Single & Dual Outputs, 200-380 VDC Input	Up to 250 VDC Out To 75 Watts	Series LPD
Full Brick Single & Dual Outputs, 18-36 VDC Input	Up to 250 VDC Out To 150 Watts	Series PA
Full Brick Single & Dual Outputs, 38-72 VDC Input	Up to 300 VDC Out To 150 Watts	Series PB
Full Brick Single & Dual Outputs, 100-180 VDC Input	Up to 300 VDC Out To 150 Watts	Series PC
Full Brick Single & Dual Outputs, 200-380 VDC Input	Up to 350 VDC Out To 150 Watts	Series PD
Full Brick Single & Dual Outputs, 36-72 VDC Input	Up to 300 VDC Out To 225 Watts	Series HPB
Full Brick Single & Dual Outputs, 100-180 VDC Input	Up to 300 VDC Out To 225 Watts	Series HPC
Full Brick Single & Dual Outputs, 200-380 VDC Input	Up to 350 VDC Out To 225 Watts	Series HPD
Single & Dual Outputs 2.4" X 2.3" X 0.5" ht -40oC / -55oC TO +85oC Operating Te	75 Watts 18-36 VDC In Up to 200 VDC Out	Series LFA/LMA
Single & Dual Outputs 2.4" X 2.3" X 0.5" ht -40oC / -55oC TO +85oC Operating Te	75 Watts 36-72 VDC In Up to 200 VDC Out	Series LFB/LMB
Single & Dual Outputs 2.4" X 2.3" X 0.5" ht -40oC / -55oC TO +85oC Operating Te	75 Watts 100-180 VDC In Up to 250 VDC Out	Series LFC/LMC
Single & Dual Outputs 2.4" X 2.3" X 0.5" ht -40oC / -55oC TO +85oC Operating Te	75 Watts 200-380 VDC In Up to 250 VDC Out	Series LFD/LMD
Single & Dual Outputs 2.4" X 4.6" X 0.5" ht -40oC / -55oC TO +85oC Operating Te	100 Watts 18-36 VDC In Up to 250 VDC Out	Series FA/MA
Single & Dual Outputs 2.4" X 4.6" X 0.5" ht -40oC / -55oC TO +85oC Operating	100 Watts 36-72 VDC In Up to 300 VDC Out	Series FB/MB
Single & Dual Outputs 2.4" X 4.6" X 0.5" ht -40oC / -55oC TO +85oC Operating	100 Watts 100-180 VDC In Up to 250 VDC Out	Series FC/MC
Single & Dual Outputs 2.4" X 4.6" X 0.5" ht -40oC / -55oC TO +85oC Operating	100 Watts 200-380 VDC In Up to 350 VDC Out	Series FD/MD
Single & Dual Outputs All Military Components .5"x1.25"x.3"ht	1.25 Watts 3.3-500 VDC Out	Series M/MV

Single & Dual Outputs Surface Mount from .5" x .5" x 0.3"ht	1.25 Watts 3.3- 250 VDC Out	Series SM
Single & Dual Outputs Surface Mount 0.200" ht	0.75 Watts 3.3-15 VDC Out	Series SAT
Single & Dual Outputs Surface Mount DIP Package 0.200" ht	0.75 Watts 3.3-15 VDC Out	Series SDT
Single & Dual Outputs Surface Mount from .5" x .5" x .44"ht	1.25 Watts Up to 500 VDC Out	Series SMV
Single & Dual Outputs Surface Mount from .5" x .5" x .54"ht	1.25 Watts 600 - 1000 VDC Out	Series SMV
Single Output Variable Output 1.43" x 1.24" x .43"ht.	4 Watts 100-500 VDC Out	Series SVV
Single & Dual Outputs Surface Mount from .7" x 1.12" x .3"ht	2.5 Watts 3.3-48 VDC Out	Series SB
Single & Dual Outputs Surface Mount from 1.12" x 1.24" x .3"ht	4 Watts 3.3-48 VDC Out	Series SC
Single & Dual Outputs Surface Mount 1.12"x 2.0" x 0.4"ht	7 Watts 3.3-48 VDC Out	Series SE

Switching Supply Regulated, Isolated Single, Dual & Triple Outputs Lowest Profile 0.5" ht.	Up to 10 Watts 115 VAC or 220 VAC 5 to 28 VDC Out	Series 10AC
Switching Supply Regulated, Isolated Single, Dual & Triple Outputs Lowest Profile 0.5" ht.	Up to 30 Watts 115 VAC or 220 VAC 5 to 28 VDC Out	Series 30AC
Switching Supply Regulated, Isolated Single, Dual & Triple Outputs Lowest Profile 0.5" ht.	Up to 55 Watts 115 VAC or 220 VAC 5 to 28 VDC Out	Series 50AC
Switching Supply Regulated, Isolated Single & Dual Lowest Profile 0.5" ht.	Up to 5 Watts 115 VAC or 220 VAC 5 to 24 VDC Out	Series 5AC
Power Factor Corrected Universal AC Input 85 - 265 VAC Output Isolated Fixed Frequency	Isolated Output 5 - 48 VDC Output Up to 300 Watts	Series AC1
30-40-65 Watts Universal Input Switcher Supply 85-264 VAC PCB OPEN FRAME Multiple Output	Up to 65 Watts	Series OFU
Regulated, Isolated, Industrial Switcher Low Profile 0.5" ht	Up to 15 Watts 3.3 - 48 VDC Out	Series SW
Power Factor Corrected Universal AC Input 5-48 VDC Out	Up to 200 Watts Out Isolated Output	Series UAC
Power Factor Corrected - Isolated Universal AC Input 85-265 VAC Input	Up to 250 Watts Out Up To 300 VDC Out	Series UACHV
Universal Input: Regulated, Isolated: Single/Dual Output: Terminal Strip Low Profile 0.625"	Up to 20 Watts 3.3 - 48 VDC Out	Series UWC
Universal Input: Regulated, Isolated: Single/Dual Output Low Profile 0.5" ht.	Up to 50 Watts 3.3 - 48 VDC Out	Series UWD
