Nuova傳感器
德國Nuova提供可靠性的設備和配件。 |
Nuova氧氣傳感器產品
.jpg) |
 |
 |
 |
E-09/0 |
E-11/0 |
E-14/0 |
E-14/S |
Connector: 3-pin wired Molex |
Connector: AMP350777-1 2 way mating lock Measuring Range: 0-100% O2 Output signal: 8.5-12.5mV Response time: < 17 seconds Warranty: 16 months Storage: up to 6 months |
Connector: 0.141" miniature phone plug on cable Measuring range: 0-100% O2 Output signal: 8–12 mV Response time: < 17 seconds Warranty: 16 months Storage: up to 6 months |
Connector: phone plug with cable Measuring range: 0-100% O2 Output signal: 8-12 mV Response time: < 17 seconds Warranty: 16 months Storage: up to 6 months |
 |
|
 |
 |
E-15/0 |
E-15/2 |
E-15/4 |
E-15/5 |
| Connector: 3 contact rings gold plated Measuring range: 0-100% O2 Output signal: 14–20 mV Response time:< 17 seconds Warranty: 16 months Storage: up to 6 months |
Connector: 3 contact rings Measuring range: 0-100% O2 Output signal: 14.–20 mV Response time: < 12 seconds Warranty: 15 months Storage: up to 6 months |
Connector: modular jack Measuring range: 0-100% O2 Output signal: 8–12 mV Response time: < 16 seconds Warranty: 16 months Storage: up to 6 months |
Connector: 3.5 mm mono jack Measuring range: 0-100% O2 Output signal: 8–12 mV Response time: < 16 seconds Warranty: 16 months Storage: up to 6 months |
 |
 |
 |
 |
E-15/5M |
E-16/0 |
E-16/HTT |
E-17/A2 |
| specification as E-15/5 however different housing to fit for Mindray WATO EX-35 | Connector: 3-pin Molex Measuring range: 0-100% O2 Output signal: 9.5-16 mV Response time: < 12 seconds Warranty: 16 months Storage: up to 6 months |
Connector: 3-pin Molex Measuring range: 0-100% O2 9.5-16 mV Response time: 12 s at flow >2l/min Warranty: 12 months Storage: up to 6 months |
Connector: 3-pin Molex Measuring range: 0-100% O2 Output signal: 8–12.5 mV Response time: < 15 seconds Warranty: 16 months Storage: up to 6 months |
 |
 |
 |
 |
E-17/A2A |
E-17/A2MH3 |
E-17/A4 |
E-17/J |
| Connector: 3 pin Molex Measuring Range: 0-100% O2 Output signal 8-12.5 mV Response time:: < 15 seconds Warranty: 16 months Storage: up to 6 months |
Connector: 3 pin Molex Measuring Range: 0-100% Output Signal: 10-13mV Response time: 4 seconds Warranty: 12 months Storage: up to 6 months currently n/a |
Connector: 3-pin Molex Measuring range: 0-100% O2 Output signal: 11-14 mV Response time: < 12 seconds Warranty: 12 months Storage: up to 3 months |
Connector: 3.5 mm mono jack Flow diverter to be ordered seperately Measuring range: 0-100% O2 Output signal: 13–16-5 mV Response time: < 12 seconds Warranty: 16 months Storage: up to 6 months |
 |
 |
 |
 |
E-17/M |
E-25/0 |
E-33/1 |
|
| Connector: 3-pin Molex Measuring range: 0-100% O2 Output signal: 12.5-16.5 mV Response time: < 12 seconds Warranty: 16 months Storage: up to 6 months |
Connector: straight power jack Measuring range: 0-100% O2 Output signal: 9–14.5 mV Response time: < 12 seconds Warranty: 16 months Storage: up to 6 months |
E-33/0 Connector: gold plated Contact rings Measuring range: 0-100% O2 Output signal: 200 μA Response time: < 20 seconds Warranty: 16 months Storage: up to 3 months |
Connector: double wired PCB plug Measuring range: 0-100% O2 Output signal: 200 μA Response time:< 20 seconds Warranty: 16 months Storage: up to 3 months |
 |
 |
 |
 |
E-43/0 |
E-47/0 |
E-55/0 |
E-60/0 |
| Connector: gold plated contact rings Measuring range: 0-100% O2 Output signal: 25–35.5 mV Response time: < 17 seconds Warranty: 12 months Storage: up to 3 months always 2 pcs per pack |
AMP phone jack 4P4C Measuring range: 0-100% O2 Output signal: in accordance with Hudson 5801 analyzer Response time: < 12 seconds Warranty: 16 month Storage: up to 6 months |
Connector: 4-pin male socket
|
Connector: AMP phone jack Flow diverter to be ordered seperately Measuring range: 0-100% O2 Output signal: 3.8-4.8 mV Response time: < 12 seconds Waranty: 16 months Storage: 4 months |
|
 |
 |
 |
E-60/LF長壽命傳感器 |
E-75/A |
E-75/1 |
E-75/4 |
| (LONG LIFE SENSOR) Lead-free, ROHS compliant Connector: 3 pin Molex Measuring range: 0-100% Output signal: 0.8-1.25 V Response time: < 5 seconds Warranty: 24 months Storage: up to 6 months |
Connector: AMP phone jack Measuring range: 0-100% O2 Output signal: 8.5 - 13.5 mV Response time: < 15 seconds Warranty: 24 months Storage: up to 6 months currently n/a |
Connector: AMP Measurng range: 0-100% O2 Output signal: 10 - 14 mV Response time: < 13 seondcs Warratny: 22 months Storage: up to 6 months currently n/a |
Connector: NESJ25 Measuring range: 0-100% O2 Output signal: 10-14 mV Response time < 13 seconds Warranty: 22 months Storage: up to 6 months currently n/a |
 |
 |
 |
 |
E-75/6 E-75/8 |
E-75/9 (New) |
E-75/13PB |
E-75/HL |
| Connector: E-75/KE6: SM2SH 2pol Connector: E-75/KE8: IP40 3pol Measruring range: 0-100% O2 Output signal: 10-14 mV Response time: < 13 seconds Warranty and Storage as E-75/4 currently n/a |
Connector: 3.5 phone jack
|
compatible to Puritan Bennett sensor PB10097559 currently n/a |
Connector: 3 pin phone connector Measuring Range: 0-100% O Output signal: 10-13.5mV Response time: 13 seconds Warranty: 15 months Storage: up to 6 months currently n/a |
 |
 |
 |
|
E-77/0 |
E-77/0S |
E-8000 |
|
| Connector: RJ11 modular plug 4P4C Flow diverter to be ordered sperately Measuring range: 0-100% O2 Output signal: 7.5–13.0 mV Response time: < 12 seconds Warranty: 16 months Storage: up to 6 months |
Connector: RJ11 modular jack Flow diverter to be ordered seperately Measuring range: 0-100% O2 Output signal: 9-13 mV Response time: < 15 seconds Warranty: 16 months Storage: up to 6 months |
Connector: 3 gold plated contact rings Measuring range: 0-100% O2 Output signal: 14.5–20 mV Response time: < 12 seconds Warranty: 16 months Storage: up to 6 months |
